Dispensing / Sampling Booth (RLAF)

Industry / Area	Application	Purpose / Benefit
Pharmaceuticals	Sampling and weighing of APIs and excipients	Prevents cross-contamination and ensures clean handling
Chemicals	Dispensing of hazardous or fine chemical powders	Protects operators from inhalation and maintains workplace safety
Food & Beverages	Handling of food-grade powders and additives	Maintains hygiene and prevents contamination
Biotechnology & R&D Labs	Media preparation, reagent handling, and powder weighing	Ensures a sterile and controlled environment
Cosmetics & Nutraceuticals	Dispensing of raw cosmetic powders or herbal extracts	Ensures GMP compliance and a safe, dust-free environment
Powder Processing Units	Weighing and transferring of bulk powders	Provides dust control and protects both operator and product

For More Technical Information Download The Catalogue

Controlled Environment

Provides a clean, dust-free, and controlled space for weighing, dispensing, and sampling of powders and granules.
Ergonomic Design Stainless steel (SS 304/316) construction with smooth, rounded corners for easy cleaning and GMP compliance. (Optional)

HEPA Filtration System

Equipped with HEPA filters (H13/H14 grade) for rapping fine airborne particles and preventing contamination

Laminar Airflow

Vertical or downward laminar airflow ensures continuous flushing of airborne dust away from the operator’s breathing zone

Product & Environment Protection

Ensures cross-contamination-free operations. Maintains ISO Class 5–8 clean air in the working zone depending on design.

Airflow Monitoring

Illumination

Energy-efficient LED/fluorescent lights with proper lux levels inside the working zone.

Noise & Vibration Control

Designed for low noise (<65 dB) and minimal vibration for comfortable long-duration use.

Safety Interlocks

Sometimes provided with UV light interlocks, differential pressure alarms, and safety shutdown systems.

Compliance

Meets GMP, GLP, and regulatory standards of pharmaceutical, food, and chemical industries.

Type of Airflow: Vertical Laminar Air Flow with reverse flow at operator level
Air Velocity: 0.45 ± 0.05 m/s (across work zone)
Primary Filter: Pre-filter (10 μm, 90% efficiency)
Secondary Filter: Fine filter (5 μm, 95% efficiency)
Final Filter: HEPA Filter H13/H14 (0.3 μm, 99.97% efficiency)
Air Recirculation: Vertical recirculation
Air Cleanliness: ISO Class 5 (as per ISO 14644-1)
