MUFFLE FURNACE 1400 °C

KEY FEATURES

• Maximum Temperature: 1400 °C
• Working Temperature Range: Up to 1350 °C (continuous), 1400 °C (intermittent)
• Step-down transformer based design reduces incoming high line voltage to a safer, controlled voltage for the heating elements.
• Double-walled construction with high-grade insulation ceramic fiber/zirconia wool to minimize heat loss.
• MS duly powder-coated outer body for durability and resistance to corrosion
• Heating Elements: Silicon carbide rods
• Uniform Temperature: Optimized placement of elements ensures uniform chamber heating.
• Temperature Control:
• Digital PID temperature controller
• Programmable temperature profile
• Temperature Accuracy: ±1 °C
• Door Type: Front-opening with ceramic fiber insulation
• Power Supply: 230V AC (Single Phase) or 440V AC (Three Phase), 50/60Hz
• Safety Features:
• Over-temperature protection
• Automatic cut-off for door opening
• Fuse & thermal safety interlocks
